Scientific Image Gallery
Welcome to our Scientific Image Gallery. Here you can find real-life examples of cell images, mostly (but not only) from peripheral blood films, that illustrate typical morphologic characteristics pointing to specific conditions or disorders. This constitutes their diagnostic value.
Click on an image to enlarge it and display a short description.
Large lymphocytes have a diameter up to 15 μm with a variable amount of cytoplasm, varying from deep to pale blue, sometimes containing large, dark staining, azurophilic granules.
<p>Large lymphocytes have a diameter up to 15 μm with a variable amount of cytoplasm, varying from deep to pale blue, sometimes containing large, dark staining, azurophilic granules.</p>
Lymphocyte on top of a monocyte. Note the different colour shades of the cytoplasm as well as different shapes of the nucleus.
<p>Lymphocyte on top of a monocyte. Note the different colour shades of the cytoplasm as well as different shapes of the nucleus.</p>
Small lymphocyte in the upper left, monocyte in the centre, neutrophil in the lower left of the high-power field. Mild platelet aggregation.
<p>Small lymphocyte in the upper left, monocyte in the centre, neutrophil in the lower left of the high-power field. Mild platelet aggregation.</p>
Both cells are typical lymphocytes. Rat lymphocytes may have either wide or narrow areas of cytoplasm and occur in various sizes.
<p>Both cells are typical lymphocytes. Rat lymphocytes may have either wide or narrow areas of cytoplasm and occur in various sizes.</p>
Metamyelocyte with a smooth, doughnut-shaped nucleus and bluish cytoplasm. Metamyelocytes are usually not found in the peripheral blood of rats. This blood smear is of an aged animal showing a picture of anaemia.
<p>Metamyelocyte with a smooth, doughnut-shaped nucleus and bluish cytoplasm. Metamyelocytes are usually not found in the peripheral blood of rats. This blood smear is of an aged animal showing a picture of anaemia.</p>
Rat monocyte with distinctive characteristics such as the colour shade of the cytoplasm and presence of vacuoles. The nucleus has a sharp notch.
<p>Rat monocyte with distinctive characteristics such as the colour shade of the cytoplasm and presence of vacuoles. The nucleus has a sharp notch.</p>
Rat neutrophils have pale cytoplasm with fine, diffuse granules. The nucleus is highly segmented, coiled, or ribbon-like with numerous indentations. This cell’s doughnut-shaped nucleus is folded.
<p>Rat neutrophils have pale cytoplasm with fine, diffuse granules. The nucleus is highly segmented, coiled, or ribbon-like with numerous indentations. This cell’s doughnut-shaped nucleus is folded.</p>
The nucleus of rat neutrophils is highly segmented, coiled, or ribbon-like with numerous indentations. The cytoplasm is pale with fine, diffuse granules. Mild platelet aggregation.
<p>The nucleus of rat neutrophils is highly segmented, coiled, or ribbon-like with numerous indentations. The cytoplasm is pale with fine, diffuse granules. Mild platelet aggregation.</p>
Blood smear with target cells, hypo- and polychromasia.
<p>Blood smear with target cells, hypo- and polychromasia. </p>
